Clock
Security Limits
Access Factory
Code Write Read Scroll High Low Incr Parameter Settings
153 0 0 NO 2088 1989 1 Set Time Clock - Year 2001
• Enter the four digits of the current year.
Security Limits
Access Factory
Code Write Read Scroll High Low Incr Parameter Settings
154 0 0 YES 12.31 1.01 1.1 Set Time Clock - Month . Day 1.01
• Enter the month to the left and the day to the right of
the decimal point.
• If the number of the day is a single digit, the digit
must be preceded by a zero.
Security Limits
Access Factory
Code Write Read Scroll High Low Incr Parameter Settings
155 0 0 YES 23:59 0:0 0:01 Set Time Clock - Hour : Minute 1:01
• Enter the hour and minutes based on 24-hour nota-
tion.
Security Limits
Access Factory
Code Write Read Scroll High Low Incr Parameter Settings
156 0 0 YES :59 :00 :01 Set Time Clock - Seconds :00
• If the number of seconds is a single digit, the digit is
preceded by a zero.
High-Current Lockout (cont’d)
Security Limits
Access Factory
Code Write Read Scroll High Low Incr Parameter Settings
143 1 0 YES 4 1 -- High-Current Lockout - Phase 4
(Active Trip Number)
143 1 0 YES 4 1 -- High-Current Lockout - Ground 4
(Active Trip Number)
• Indicates on which trip operation the high-current
lockout is active.
• Use PHASE/GROUND key to examine phase and
ground.
When the Form 4C control is first energized, the clock default
date is January 1, 2001 (1/1/2001). The clock must be set to
the proper date and time for the events to be properly record-
ed. (Refer to Setting The Control Clock section of this manual.)
IMPORTANT: Overcurrent protection is independent
of the clock and will respond correctly regardless of the
clock status.
