Kyle Form 4C Microprocessor-Based Recloser Control Programming Guide
The Event Recorder provides detailed, time-related
data for system analysis. Event recorder data will indi-
cate time-tagged current values for eighteen different
event types. The event types (Access Code 162) identify
the fault history for numerous applications in operation
and analysis of the distribution feeder.
Below is sample data from the event recorder. The
access codes are referenced under the appropriate
heading.
Event Recorder
CURRENT (kA)
Phase Phase Phase
Event # Event Type Month.Day Hour:Min Second Ground Bushing 1-2 Bushing 3-4 Bushing 5-6
(161) (162) (163) (164) (165) (166) (167) (168) (169)
1 2 2.17 14:20 :40 0.02 0.16 0.15 0.17
2 1 2.17 14:20 :08 2.80 0.16 0.15 2.80
3 1 2.17 14:20 :06 2.80 0.16 0.15 2.80
4 3 2.08 10:24 :15 0.00 0.00 0.00 0.00
5 1 2.08 9:21 :12 1.30 0.13 1.30 0.14
6 1 2.08 9:21 :07 1.30 0.13 1.30 0.14
7 1 2.08 9:21 :05 1.30 0.13 1.30 0.14
8 1 2.08 9:21 :03 1.30 0.13 1.30 0.14
9 2 2.03 14:40 :49 0.02 0.15 0.15 0.16
10 1 2.03 14:40 :16 2.40 2.40 0.15 0.16
11 1 2.03 14:40 :14 2.40 2.40 0.15 0.16
12 2 2.03 14:38 :40 0.02 0.15 0.15 0.17
13 1 2.03 14:37 :08 2.80 0.16 0.15 2.80
TABLE 8
Event Recorder Sample Data
Security Limits
Access Factory
Code Write Read Scroll High Low Incr Parameter Settings
160 Reset 1 0 NO 50 1 1 No. of Events Since Last Reset --
• Feature is enabled or disabled per Access Code 23
(ON/OFF).
• Displays the number of events that have occurred
since the last time Access Code 160 was reset to
zero.
Security Limits
Access Factory
Code Write Read Scroll High Low Incr Parameter Settings
161 0 0 NO 50 1 1 Event Number --
• Upon entry of Access Code 161, Event 1 will appear.
For a specific event, press the CHANGE key and
enter the event number.
• Key-in the event number for direct event interroga-
tion.
• The Form 4C control stores the 50 most recent
events.
• Data for a specific event is accessed using the
SCROLL key.
