Cooper Kyle Form 4C - Page 56

56
Kyle Form 4C Microprocessor-Based Recloser Control Programming Guide
Switch Mode
Security Limits
Access Factory
Code Write Read Scroll High Low Incr Parameter Settings
190 2 0 YES -- -- -- Switch Mode Active TCC Selection 2
(TCC1/TCC2)
• Applicable to controls with CPU Firmware versions
8.XX, 11.XX, and 12.XX only.
• Indicates whether TCC1 - phase and ground or
TCC2 -phase and ground is active when the control
is in the Switch Mode. (Reference Access Codes 02
and 03.)
Security Limits
Access Factory
Code Write Read Scroll High Low Incr Parameter Settings
191 2 0 YES 1600 50 1 Switch Mode Minimum 100
Target Sensing - Phase
191 2 0 YES 800 5 1 Switch Mode Minimum 50
Target Sensing - Ground
• Applicable to controls with CPU Firmware versions
8.XX, 11.XX, and 12.XX only.
• Minimum target sensing is a threshold value at
which a system overcurrent is detected.
• Minimum target sensing is set for both phases and
ground through a range of settings based on the
recloser’s CT ratio.
CT ratio 500:1 allows a range from 25 to 800 A
phase and 2 to 400 A ground.
CT ratio 1000:1 allows a range from 50 to 1600 A
phase and 5 to 800 A ground.
CT ratio 2000:1 allows a range from 100 to 2400 A
phase and 10 to 1600 A ground.
• All values are adjusted in increments of 1.
• The control accepts only the values within the limits
preset in the control. Attempts to enter other values
results in a LO/HI message.
• Use the PHASE/GROUND key to select phase and
ground.
