Switch Mode (cont’d)
Security Limits
Access Factory
Code Write Read Scroll High Low Incr Parameter Settings
192 2 0 YES 1600 50 1 Switch Mode Alternate Minimum 100
Target Sensing - Phase
192 2 0 YES 800 5 1 Switch Mode Alternate Minimum 50
Target Sensing - Ground
• Applicable to controls with CPU Firmware versions
8.XX, 11.XX, and 12.XX only.
• Alternate minimum target sensing is set for both
phase and ground through a range of settings based
on the recloser’s CT ratio.
CT ratio 500:1 allows a range from 25 to 800 A
phase and 2 to 400 A ground.
CT ratio 1000:1 allows a range from 50 to 1600 A
phase and 5 to 800 A ground.
CT ratio 2000:1 allows a range from 100 to 2400 A
phase and 10 to 1600 A ground.
• All values are adjusted in increments of one.
• The control accepts only the values within the limits
preset in the control. Attempts to enter other values
results in a LO/HI message.
• Use the PHASE/GROUND key to select phase and
ground.
