Back Panel
1 2 3 4 5 6 7 8 9 10
1 : Surround Inputs : Accepts Six-Channel analog inputs from a DVD or SACD player.
2 : Tape out : The record output jack permits recording directly any signal being
Reproduced by the amplifier.
3 : Tape in : Connect with the playback outputs of the tape recorder or cassette deck.
4 : Tuner :
Accepts the signal from a tuner.
5 : CDP
: Input for a CD player.
6 : AUX 1 & 2 :
Input for any high output device.
7 : Stereo out :
Outputs to stereo power amplifier.
8 : Surround outputs :
Outputs to 5 channel power amplifier and active subwoofer.
9 : 12V remote 1 & 2 : DC jack for remote on/off operation of power amplifier and
CD-Player / DVD-Player.
10 : AC Power : The AC Power Cord is plugged here.
