Copystar CS 181 - Machine Cross Section

2KJ/2KH
1-1-6
1-1-3 Machine cross section
Figure 1-1-3 Machine cross section
2
2
1
7
6
3
4
8
5
Paper path
Light path
1. Paper feed section
2. Optical section
3. Drum section
4. Developing section
5. Transfer and separation sections
6. Fuser section
7. Eject and switchback sections
8. Duplex section
