2KJ/2KH
1-2-13
5. Remove five screws and remove the rear
cover.
Figure 1-2-15
6. Cut out the aperture on the right middle
cover using nippers.
Figure 1-2-16
7. Remove two screws and remove the shield
cover.
Figure 1-2-17
Screw
Screw
Screw
Screw
Screw
Rear cover
Aperture
Right middle
cover
Shield cover
Screw
Screw
