2FT-1
1-4-30
U135
Checking toner motor operation
Description
Drives toner motor.
Purpose
To check the operation of toner motor.
Start
1. Press the start key. The screen for selecting an item is displayed.
2. Select the item using the up/down cursor keys.
Method for toner motor on
1. Press the start key. The operation starts.
2. To stop operation, press the stop/clear key.
Setting for toner motor on time
1. Change the setting using the left/right cursor keys.
2. Press the start key. The value is set.
Completion
Press the stop key after operation stops. The screen for selecting a maintenance item No. is displayed.
U144
Setting toner loading operation
Description
Sets toner loading operation after completion of copying.
Purpose
To set whether or not toner is loaded on the drum after low density copying. Normally no change is necessary
from the initial setting.
Method
Press the start key. The screen for selecting an item is displayed.
Setting
1. Select either ON or OFF using the up/down cursor keys. The selected item is displayed in reverse.
Initial setting: OFF
2. Press the start key. The value is set.
Available only when the mode is turned on.
3. Select the item using the up/down cursor keys.
4. Change the setting using the left/right cursor keys.
Example
When COUNT is 5 and PERCENT is 30, take the average in every five sheets, and perform the toner
loading operation when the printing ratio is 3% or less.
5. Press the start key. The value is set.
Completion
Press the stop/clear key. The screen for selecting a maintenance item No. is displayed.
Maintenance
item No.
Description
Display Description
MOTOR MOVING Turning the toner motor on
ON TIME Toner motor on time
Description Setting range Initial setting
Toner motor on time 1 to +10 (s) 3
Display Description
ON Toner loaded
OFF Toner not loaded
Display Description
Setting range Initial setting
COUNT Count number of sheets
1 to 50 5
PERCENT Printing ratio
10 to 40 30
