9. Target Light:
The Target Light is used to assist in cueing up the stylus more accurately in a dark environment.
10. Headshell Locking Nut:
The locking nut will securely hold the headshell to the tonearm.
11. S-Shaped Tone Arm:
The tonearm is the mechanism that holds the headshell and stylus allowing it to track across a record.
12. 33⅓ RPM Speed Selector:
Engaging this buon will rotate the plaer at 33⅓ RPM. A red LED will glow when this funcon is acvated.
13. 45 RPM Speed Selector:
Engaging this buon will rotate the plaer at 45 RPM. A red LED will glow when this funcon is acvated.
14. Pitch Adjust Slider:
This slider is used to adjust the playback pitch or plaer speed. This can be adjusted from minus 10% up to
plus 10%.
15. Tonearm Lever:
This lever is used to safely elevate the tone arm above, or to lower onto a record without endangering the
record surface.
16. Tonearm Rest and Clamp:
Safely holds the tonearm in a xed posion during periods of non-use and transportaon.
17. An-Skate Control:
Compensates for inward tracking forces when the stylus nears the centre of the record by applying an out-
ward force to the tonearm and stylus, which prevents the stylus skipping across the record.
18. Counterweight Scale:
This scale is used to properly balance the tonearm. NOTE: The counterweight scale must face toward the
user.
19. Counterweight:
The counterweight balances the tone arm and adjusts the stylus pressure.
20. Spare Stylus Holder:
This cutout has been designed to safely store a spare stylus & headshell assembly.
21. Dust Cover Hinges:
Hinges connect the dust cover to the main chassis, with a hold-up funcon to keep the dust cover open while
using the controls.
22. RCA Output Jacks:
These jacks send a low voltage Phono level output signal or high voltage Line level output signal to an ampli-
er, receiver or mixers Phono or Line input jacks.
23. Phono/Line Switch:
This switch is used to change the RCA audio output mode between Phono output or Line output.
24. USB Socket:
By connecng the Turntable to your computer via the USB cable (maximum 3.0m length). You can record
your vinyl to your hard disk using the free AUDACITY recording soware. You can download this free so-
ware at: hp://www.audacity.sourceforge.net/
*Instrucons for the use of this soware is also available from the Audacity website.
Controls & Funcons Cont’d
