21
RELOADING THE BUMP HEAD WITH
TRIMMER LINE – cont’d
3. Cut two 10' (3 m) lengths of high
quality .095 trimmer line.
4. Rotate the empty spool clockwise
until the arrows (4) align with the
eyelets (5) in the bump head
housing (Fig. 5).
5. Insert one end of one of the pre-cut
10' (3 m) trimmer lines (6) into one
of the eyelets as far as it will go.
Insert one end of the remaining
pre-cut trimmer line into the other
eyelet as far as it will go.
6. While holding the bump head
housing with one hand, turn the
spool clockwise to wind the trimmer
line onto the spool. Continue to turn
the spool clockwise until only 6"
(15 cm) of trimmer line is exposed
beyond the bump head housing.
NOTES:
a) When starting to wind the line onto
the spool, make sure the ends of
the line remain fully inserted into
the eyelets.
b) Excess line can be cut off with
scissors.
REMOVING THE SPOOL TO
RETRIEVE OR UNTANGLE TRIMMER
LINE
WARNING: Avoid Injury! To
avoid accidental start up: Always
remove the Power Cell before
removing or reinstalling the spool.
The trimmer line may break off at the
eyelet due to hitting debris. It may also
become entangled within the bump
head spool. In either case, you will have
to remove the spool from the bump
head as follows:
ASSEMBLY AND OPERATING
Fig. 5
!
