ET 66 - ET 66 M operator’s manual
INSTALLATION
WARNING
Take the utmost care when unpacking, assembling, and setting up the machine as
described in this heading.
Failure to observe these instructions can lead to damage to the machine and injury
to the operator or other persons.
Remove the original packing once you have positioned it as shown on the outside and
keep it intact for possible future transport.
Choose the place of installation in strict observance of local regulations regarding
safety in the workplace.
IMPORTANT: for correct, safe use of the equipment, users must ensure a lighting level
of at least 300 lux in the place of use.
ATTENTION
If the machine is to be installed outdoors, it must be properly protected by a canopy
roof.
Ambient conditions in the place of operation:
- relative humidity from 30% to 95% without condensation.
- temperature range from 0°C to +55°C
WARNING
The machine must not be operated in explosive atmospheres.
Place the machine in the chosen position and make sure the surrounding space is
commensurate with the minimum clearances indicated in figure 3.
Main operating components (fig.4)
A Distance gauge
B Handle for moving the machine
C Display panel with keypad
D Weight holder tray
E Brake control lever
F Master switch
G Castor wheel
H Castor wheel raising/lowering knob
I Wheel lift
L Filter regulator assembly
M 12V battery connector (only for ET66)
N Battery/mains selector (only for ET66)
O push-button valve for motor actuation (only for ET66 M)
During operation the machine must rest stably on the floor. You must therefore
disengage the castor on the left side of the machine (G, fig.4) by turning the two knobs
(H, fig.4) clockwise until the wheel detaches from the floor.
Fit the threaded hub on the spin shaft using the hex wrench.
