ET 66 - ET 66 M operator’s manual
GB
TRANSPORT, STORAGE AND HANDLING
- Before installation the balancer must be transported in its original packing by
inserting the forks of a pallet truck or lift truck in the relevant channels in the pallet,
making sure that the machine is maintained in the position indicated on the outer
packing (fig.1).
- Machine packing and shipping weight (with supplied kit):
length mm depth mm height mm weight Kg
ET 66 1350 930 1150 182
ET 66 M 1350 930 1150 195
- Ambient conditions in the place of storage:
• relative humidity between 20 and 95%
• temperature range from -10° to +60°
ATTENTION
Do not stack other goods on top of the packing or damage may result.
You can move the machine on its built-in wheels, even after it has been installed.
Before moving the machine:
- remove the power plug from the socket
- lower the castor wheel (G fig.4) located on the left side of the machine by turning the
two relevant knobs (H fig.4) counter-clockwise.;
- stow the wheel lift in its rest position (locked);
- move the machine using handle B, fig.4.
Note for ET 66
If you need to move the machine frequently you can power it from an external 12V
battery. This will require the special kit including the cables and clamps to connect the
unit directly to a car battery or a cigar-lighter socket.
To lift the machine insert the forks of a pallet truck or lift truck under it so that the c/c
centre is roughly aligned with the right side of the cabinet (fig.2). Alternatively you can
place the machine on its original pallet, secure it using the original fixing devices and
then lift the pallet, again using a pallet truck or lift truck.
ATTENTION
When moving the machine never apply force to the spin shaft.
