Corken F291 - Page 46

All dimensions are in inches (millimeters).
Appendix D—Outline Dimensions
Model 491 with 107 Mounting
48 (1,219)
25-3/4 (654)
15 (381)
18 (457)
18 (457)
9-7/16
(240)
7-1/8
(181
4
(102)
4
(102)
7-3/4
(197)
5-3/4
(146)
5-5/16
(135)
2-7/16
(62)
2-1/8
(54)
1-1/2
(38)
1-1/2
(38)
19 -1/8
(486)
33-5/8
(854)
6
(152)
1-1/4
(32)
Liquid drain
1/4" NPT
Strainer
Liquid
trap
Adjustable motor
slidebase
Electric motor
(optional)
Inlet / Outlet
4-way valve
1" NPT
46
