3.8 SUPPLEMENTARY HYDRAULIC COMMAND
Some versions may be equipped with a hydraulic force instrument for the
command of auxiliary equipment.
The hydraulic force instrument is composed of two openings with rapid transmis-
sion of standard type, indicated by the letters “A” and “B”, situated on the right side
of the dashboard.
To obtain hydraulic oil pressure on the openings you must work the auxiliary
command lever.
• To obtain pressure on the “A” opening, push the lever forward.
• To obtain pressure on the “B” opening, pull the lever backward, toward your-
self.
READ CAREFULLY: Read the user’s instructions carefully for all accessories
and/or tools that have been installed on your machine. Always refer to the
manual which was provided with them and always keep it attached to this
manual.
ML 85 additional hydraulic control
The power take-off consists of two standardised quick-release hydraulic openings,
marked with the letters "M” and “F" on an applied adhesive plate, located on the right
side of the dashboard.
• To obtain the hydraulic oil pressure on the openings, it is necessary to act on the
auxiliary control lever.
• To obtain pressure on the opening "M" push the lever forward. (lock it in that
position to have it continue)
• To obtain pressure on the opening “F” pull the lever back towards you. (lock it in
that position to have it continue)
• To obtain pressure on the mouth "B" pull the lever back towards you.
