4.
Remove the lid and clean any remaining part on
the opening.
Figure 8.
5.
Place the 28” bar from the kit in the front pocket
as shown in Figure 9.
For the 32” ice maker turn black tabs on bar
down
. Apply RTV on each end of the bar to fill
gap between bar and hopper as shown in Figure
10
For a 22” ice maker turn black tabs on bar and
use
(2) front to rear bars. Apply RTV on each
end of the bar to fill gap between bar and hopper
as shown in Figure 11.
Figure 9.
Figure 10.
Figure 11.
6.
Add some RTV (Silicon), all around the exterior
line, as shown. Place the cut lid on top of the ice
bin.
Figure 12.
Adapter Lid For 255/215 - Installation Instructions
©2018, Cornelius Inc. - 5 - Publication Number: 548000078INS
