IntelliCarb Drop-In Ice Cooled Installation Guide
© 2003-2017, Cornelius Inc. - 7 - Publication Number: 630460204INS
INSTALLATION
It is the responsibility of the installer to ensure that the water supply to the dispensing equipment is provided with
portion backflow by an air gap as defined in ANSI A112.1.2-1979; or an approved vacuum break or other such
method as proved effective by test and must comply with all federal, state and local codes.
Failure to comply could result in serious injury, death or damage to the equipment.
Water pipe connections and fixtures directly connected to a potable water supply shall be sized, installed and main-
tained in accordance with Federal, State and Local laws.
INSTALLATION REQUIREMENTS
Weight: counter must be level and able to support 450 lbs.
Environment: indoor installation only
Temperature: 40 to 100° F ambient temperature
CO2:
75 psi at unit
Syrup:
60 psi. min.,.70 –.75 ounces per sec., not to exceed
3.75 oz/sec Finished Product Flow Rate (.6 gpm) at
unit
Water Pressure 60 psi max. at pump
Electrical: - see name plate
Water Volume 125 gph
Product Supply Beverage Tubing .375 min.
