GENERAL DESCRIPTION
This section gives the Unit description, theory of operation, and design data for
IMPORTANT: To the user of this manual – This manual is a guide for installing, operating, and main-
taining this equipment. Refer to the Table of Contents for page location for detailed information per-
taining to questions that arise during installation, operation, service, or maintenance of this equip-
ment.
FREIGHT DAMAGE CLAIMS PROCEDURE
The deliver of your equipment (freight company, distributor, or dealer) is responsible for loss or damage of your
shipment. All claims must be filed with the deliverer of your equipment. Please follow the steps below to deter-
mine is your shipment is satisfactory or if a claim must be filed.
1. Check the number of products delivered against the number of products listed on the delivery receipt.
Should the totals not match, have the driver note all error on both copies and both you and the driver sign
and ate said notation.
2. Inspect all cartons for visible damage. Open and inspect as required before the driver leaves and have him
or her note any damage on the receipts. All damaged claims must be inspected within 15 days of delivery.
Notify your carrier immediately if concealed damage is found after delivery.
3. Should concealed damage be found when product is unpacked, retain the packing material and the product
and request an inspection from the deliverer.
4. All claims for loss or damage should be filed at once. Delays in filing will reduce the chance of achieving a
satis factory resolution to the claim.
SPECIFICATIONS, ICE CUBER
The following table contains equipment specification information for the Ice Cubers.
MODEL IACS224 IACS224E50 IWCS224 IWCS224E50
UNIT
Volts 115 220 115 220
Phase 1 1 1 1
Hertz 60 50 60 50
No. Wires 2+Ground 2+Ground 2+Ground 2+Ground
MIN. CIRCUIT MAX FUSE SIZE (HVAC CIRCUIT BREAKER REQUIRED)
Amps 20 15 20 15
MAX FUSE SIZE (HVAC CIRCUIT BREAKER REQUIRED)
Amps 20 15 15
REFRIGERANT
Type R404A(HP62) R404A(HP62) R404A(HP62) R404A(HP62)
Weight (oz) 13 13 13 13
Weight (g) 369 369 369 369
COMPRESSOR
Volts 115 220 115 220
Phase 1 1 1 1
Hertz 60 57 60 57
LRA 37.2 16.1 37.2 16.1
RLA 7.1 2.8 7.1 2.8
