Corsair Carbide series Installation Guide

SPEC-03
43
ENGLISH
Accessory Kit Contents
a
x4
Cable ties
g
x1
Motherboard
standos
e
x16
Short fan screws
d
x4
SSD pan head
screws
f
x4
Long fan screws
b
MBD/HDD screws
x10
c
x16
SSD/ODD screws
Case Features
I/O panel (x2 USB 3.0, Headphone/Mic, and Power/Reset)
Removable front fascia
Front 120mm LED intake fan with x2 140mm fan compatibility
Rear 120mm exhaust fan
x2 Top 120mm fan mounts
Windowed side panel
x3 5.25" Tool-free drive bays
Bottom PSU mount and dust filter
Front dust filter and mesh cover
x2 Tool-free 2.5" drive mounts
Top dust filter with pins
x2 Tool-free removable ODD covers
CPU backplate cutout
A
B
C
D
E
F
G
H
I
J
L
K
M
LM
Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.

Corsair Carbide series Specifications

General

Type	Mid Tower
Motherboard Support	ATX, Micro-ATX, Mini-ITX
Material	Steel, Plastic
Expansion Slots	7
Front I/O Ports	1 x Headphone, 1 x Microphone
Radiator Support	120mm rear
Drive Bays	2 x 2.5", 2 x 3.5"
