Corsair Carbide series Installation Guide

SPEC-03
1211
ENGLISH
Frequently Asked Questions
1. How do I remove the I/O Panel ?
If needed, you can uninstall your I/O panel by removing the front
fascia (step 6) then unscrewing the 2 screws at each side of
panel. (drawing)
2. Does the polarity matter with the I/O panel’s power and reset
header?
No, only the LED headers.
3. Who should I contact if I received my case damaged or one of the
fans is no longer working?
Please go to corsair.force.com and request an RMA
so that we can replace the damaged part(s).
4. Where can I mount a fan?
To learn more about this case visit the product page at corsair.com
STEP 11
Fan Mount Locations
Front x2 120mm or x2 140mm
Top x2 120mm
Rear 120mm
Bottom 120mm
Side x
Mid x
Frequently Asked Questions
1
2
3
4
1
4
2
3
Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.

Corsair Carbide series Specifications

General

Type	Mid Tower
Motherboard Support	ATX, Micro-ATX, Mini-ITX
Material	Steel, Plastic
Expansion Slots	7
Front I/O Ports	1 x Headphone, 1 x Microphone
Radiator Support	120mm rear
Drive Bays	2 x 2.5", 2 x 3.5"
