Cotech LS5T-52 User Manual

13
ENGLISH
Number Name Qty
1 Screw M6×15 2
2 Handle 1
3 Cover 1
4 Screw M8×20 4
5 Cylinder 1
6 Piston 1
7 Piston sealing 1
8 O-ring gasket 1
9 Drawbar 4
10 Front side 1
11 Piston sealing 1
12 Piston rod 1
13 Locking pin 1
14 Operations 2
15 Pressure plate and length
setting
1
16 Spring protection/support
for log (left)
1
17 Operations 2
18 Splitter 1
19 Return springs 2
20 Holder 4
21 Screw M6×10 16
22 Spring washer M6 8
23 Spring protection/support
for log (right)
1
24 Bolt M8×12 5
25 Nut M8 7
26 Braces 1
27 Bolt M8×30 1
28 Pump side 1
29 Side bearing bushing 4
30 O-ring gasket 2
31 Locking ring 2
32 Pin B8×24 2
33 Steel ball 2.5 1
34 Axel 1
35 Pump wheel 2
36 Pump house 1
37 Bolt M5×185 3
38 Side motor/pump 1
39 Gasket 4
40 Spring washer M5 4
41 Sealing 1
Number Name Qty
42 Feather key 1
43 Nut M5 3
44 Motor with switch 1
45 Bolt M8×30 6
46 Spring washer M8 11
47 Washer M8 9
48 Spring for safety valve 1
49 Steel ball 6 1
50 O-ring gasket 2
51 Adjusting screw for safety
valve
1
52 O-ring gasket 1
53 Screw 1
54 Bolt M5×8 1
55 Cover for operating lever 1
56 Screw M6×35 2
57 Operating lever -
58 Knob 1
59 Hub cap 2
60 Locking ring 2
61 Wheel 2
62 Wheel bracket 1
63 Operating lever, complete 1
64 Tube cotter pin -
65 Locking ring 1
66 Spring 1
67 Valve piston 1
68 O-ring gasket 1
69 Sleeve 1
70 O-ring gasket 5
71 Valve cylinder 1
72 O-ring gasket 1
73 Rear side 1
74 Spring 1
75 O-ring gasket 1
76 Plug 1
77 Gasket 4
78 Domed cap nut 4
79 O-ring gasket 1
80 Bleeding screw 1
81 Packing 1
82 Dipstick/oil plug 1
