Cotek SE200-124 - Page 12

8
EN
Electrical
Specification
Model No.
Item
SE400-212
SE400-224
SE400-248
Input
Voltage
12VDC
24VDC
48VDC
Voltage Range
10.5~16.0VDC
21.0~32.0VDC
42.0~64.0VDC
No Load Current
<1A @12VDC
<0.5A @24VDC
<0.25A @48VDC
Power Saving Mode
<0.2A @12VDC
<0.1A @24VDC
<0.05A @48VDC
Efficiency (Typ.)
88%
89%
90%
On Mode @ Save Mode
<1A @12VDC
<0.5A @24VDC
<0.25A @48VDC
On Mode @ No Load Mode
<0.2A @12VDC
<0.1A @24VDC
<0.05A @48VDC
Output
Continuous Output Power
400 W (± 3%)
Max. Output Power (1Min.)
> 400 W~460 W (100%~115%)
Surge Power (1Sec.)
< 800 W
Frequency
50 / 60 Hz ± 0.5% (Dip Switch Selectable)
Output Voltage
200 / 220 / 230 / 240 VAC ± 5% (Dip Switch Selectable)
Short-Circuit Protection
1 Sec Shutdown
Output Waveform 
Pure Sine Wave (THD < 5%@ Normal Load)
Protection
Input Over-Voltage
Protection 
16.0 ± 0.3VDC
32.0 ± 0.5VDC
64.0 ± 1.0VDC
Input Under-Voltage
Protection
10.5 ± 0.3VDC
21.0 ± 0.5VDC
42.0 ± 1.0VDC
BAT. Low Shutdown
10.5 ± 0.3VDC
21.0 ± 0.5VDC
42.0 ± 1.0VDC
BAT. Low Alarm
10.5 ± 0.3VDC
21.0 ± 0.5VDC
42.0 ± 1.0VDC
BAT. Low Restart
14.5V± 0.3V
28.0 ± 0.5VDC
56.0 ± 0.5VDC
BAT. High Shutdown
16.0 ± 0.3VDC
32.0 ± 0.3VDC
64.0 ± 0.3VDC
BAT. High Restart
12.5V± 0.3V
25.0V± 0.3V
50.0± 0.3V
Environment
Working Temp. 
-20 ℃~40 ℃
Storage Temp.
-30 ℃~70 ℃
Working Humidity
10~95% RH, non-condensing
Safety &
EMC
Safety Standards
Certified EN 62368-1
EMC standards
Certified EN55032 class B; EN 55024; EN 61000-3-2, -3-3
IEC61000-4-2, 3, 4, 5, 6, 8, 11
E-mark
Certified CISPR 25; ISO11452-2; ISO 7637-2
Others
Dimension(WxHxD)
150 mm X 68mm X187 mm
Weight
1.256kg
Remote Control
CR-8 (optional)
Cooling
Temperature & Load Controlled cooling Fan
Table 5. SE400 for output 200/220/230/240 VAC specification
Note：
 Normal load Condition：Vin =12.5V/25V/50V, Vo=200/220/230/240 VAC 80% load
(PF=1.0)
 Voltage performance：Please refer to Figure 2
 Temperature performance：Please refer to Figure 3
