2-3. Electrical Specification
2-3-1. SE200 Specification
Electrical
Specification
Model No.
Item
SE200-112
SE200-124
SE200-212
SE200-224
Input
Voltage
12VDC
24VDC
12VDC
24VDC
Voltage Range
10.0~16.0VDC
20.0~32.0VDC
10.0~16.0VDC
20.0~32.0VDC
No Load Current
< 0.5A
< 0.4A
< 0.5A
< 0.4A
Power Saving Mode
< 0.12A
< 0.06A
< 0.12A
< 0.06A
Efficiency (Typ.)
89%
91%
91%
93%
On Mode @ Save Mode
< 0.12A
< 0.06A
< 0.12A
< 0.06A
On Mode @ No Load Mode
< 0.5A
< 0.4A
< 0.5A
< 0.4A
Output
Continuous Output Power
200 W
Over Rated Power
(3 Min.)
230 W
Peak Power (3 Sec.)
250 W
Frequency
50 / 60 Hz ± 0.5% (Dip Switch Selectable)
Output Voltage
100 / 110 / 115 / 120 VAC ± 5%
(Dip Switch Selectable)
200 / 220 / 230 / 240 VAC ± 5%
(Dip Switch Selectable)
Short-Circuit Protection
2 seconds and restart 3 times shutdown
Output Waveform
Pure Sine Wave (THD < 3%@ Normal Load)
Protection
Input Over-Voltage
Protection
16.0VDC ± 3%
32.0VDC ± 3%
16.0VDC ± 3%
32.0VDC ± 3%
Input Under-Voltage
Protection
10.0VDC ± 3%
20.0VDC ± 3%
10.0VDC ± 3%
20.0VDC ± 3%
BAT. Low Shutdown
10.0VDC ± 3%
20.0VDC ± 3%
10.0VDC ± 3%
20.0VDC ± 3%
BAT. Low Alarm
10.5VDC ± 3%
21.0VDC ± 3%
10.5VDC ± 3%
21.0VDC ± 3%
BAT. Low Restart
12.5VDC ± 3%
25.0VDC ± 3%
12.5VDC ± 3%
25.0VDC ± 3%
BAT. High Alarm
15.5VDC ± 3%
31.0VDC ± 3%
15.5VDC ± 3%
31.0VDC ± 3%
BAT. High Shutdown
16.0VDC ± 3%
32.0VDC ± 3%
16.0VDC ± 3%
32.0VDC ± 3%
BAT. High Restart
14.5VDC ± 3%
29.0VDC ± 3%
14.5VDC ± 3%
29.0VDC ± 3%
Environment
Working Temp.
-20 ℃~60 ℃
Storage Temp.
-30 ℃~70 ℃
Working Humidity
10~95% RH, non-condensing
Safety &
EMC
Safety Standards
----
Certified EN 60950-1
EMC standards
Certified FCC class B
Certified EN55022; EN61204-3
EN61000-6-1, 6-3
EN61000-3-2, -3-3; EN55024
EN61000-4-2, 3, 4, 5, 6, 8, 11
E-mark
----
Certified CISPR 25; ISO 7637-2
Others
Dimension(WxHxD)
150 mm X 68mm X187 mm
Weight
1.6kg
Remote Control
CR-8 (optional)
Cooling
Temperature & Load Controlled cooling Fan
Table 1. SE200 specification
Note：
This test condition is normal DC input and temperature 25℃
