Table 14. SE series power saving load
3-2. Rear Panel Introduction
Figure 8. SE series rear panel view
Table 15. SE series rear panel introduction
3-2-1. DC Input Terminal
The DC cables should be as short as possible (less than 6 feet / 1.8
meters ideally)
The size of the cable should be thick enough to limit the voltage
drop to less than 2% when carrying the maximum input current to
prevent frequent low-input voltage warnings, and shutdown.
The following sizes of cables and fuses are recommended distance
(<6 ft.) between the batteries and the inverter.
