APPENDIX TO COTES LIGHTWEIGHT USER MANUAL
1/3
Cotes dehumidifier: CL26
Manual number: 140778 – appendix 1
Revision: .
COTES.COM
APPENDIX 1 – TECHNICAL DETAILS
SERIAL NUMBER/IDENTIFICATION
The nameplate with the serial number of this specific model is located on the control panel of the dehumidifier.
SPECIFICATIONS
Please note that specifications and controls given in this handbook are in some situations approximate.
Table 1 Technical data
SPECIFICATIONS
CL26
High Capacity mode
CL26
Low Energy mode
Dry air, free blowing
m
3
/hour
500
500
Dry air, nominal
m
3
/hour
350
250
Regeneration air, nominal
m
3
/hour
65
40
External pressure, dry air, nominal
Pa
130
180
External pressure, regeneration air, nominal
Pa
280
280
Capacity at 20C, 60% RH
Kg/24h
26,4
19,2
Power consumption, Nominal
kW
1,46
0,84
Voltage/Phases
V / Ph
220-230 / 1PH+N+PE
Internal thermal fuse
°C
84
External fuse in connected installation
A
Min. 10 / Max. 16
Type of distribution system
TN-S
IP rating (With both outlet ducts connected)
IP33
Sound level: Nominal / Free blowing, at 1m
dB(A)
66 / 69
60 / 69
650130
CL26 dehumidifier
YY.XXXXXX
10,8
230V PH+N+PE
50
1,4
1,57
Serial number example:
24.12345
12345 = Serial number
24 = Year of production
IP33
