Cotes LIGHTWEIGHT CL26 - Main Components

COTES LIGHTWEIGHT - USER MANUAL
7/18
Cotes dehumidifier: CL26
Manual number: 140778
Revision: A
COTES.COM
2.3 MAIN COMPONENTS
1. Cable strap
2. Dry Air Outlet
3. Air fan
4. Drive belt
5. Gearmotor for rotor
6. Filter (Standard - G4)
7. Regeneration Air Outlet
8. Flexible hose
9. Desiccant rotor
10. Heater
11. Filter lid
See section
6 / SERVICE AND MAINTENANCE for information on how to access main components.
Optional accessories
Cotes Lightweight dehumidifiers can be fitted with the following optional accessories:
DESCRIPTION
Analogue hygrostat (Cotes DR10).
Cotes Window Kit
Bracket for wall mounting (with or without magnets)
Pipe adapter for inlet air (1 port and 2 port versions)
Contact Cotes for more details about optional accessories.
1
4
5
7
10
6
3
2
9
8
11
