Note: As part of a Software Upgrade, you may have been supplied with a more recent version
of the CourtyardSystemUpdate program – always use the most recent version to upload your
new software.
Uploading Patfiles & Xilfiles
Ensure that the CY460 SPG is ON.
On your PC, run the “CourtyardSystemUpdate_v6.0.0.0.exe” program.
In the dialog boxes, enter the IP Address and IP Mask to be those of the CY460 SPG.
Select the [ Get Device Mode ] button.
The status dialog window should confirm the mode :
“The device is in APPLICATION mode” confirmation appears in the window.
If the CY460 SPG is “not found”, check again that all connections have been made
and that the IP Addresses have been entered correctly, then try repeating the above
procedure after re-booting the CY460 SPG, and then restarting the
CourtyardSystemUpdate program.
If the CY460 SPG still cannot be found, contact Courtyard for further assistance.
Select the [ Open File ] button.
Select the relevant “ *.ATA ” file i,e, XIL……ata or PAT……ata.
Select the [ Send to device ] button. Upload of file takes ~ 1 min.
The progress bar message should confirm that the upload was completed successfully. If not,
try selecting [ Send File To Device ] again. If the file still cannot be uploaded, contact
Courtyard for further assistance.
Now Power Cycle the CY460 SPG.
Uploading ArmFiles
To upload ArmFiles to a CY460 SPG, the CY460 SPG needs to be in “Bootloader” mode.
This is achieved by holding down the blue push button on the front panel, before applying
power to the unit. After 5 seconds, the LCD screen should confirm that the CY460 SPG is in
Bootloader Mode, and should also confirm the IP addresses and current software version
numbers of the unit. You can now release the button.
Continuing similar to above :
On your PC, run the “CourtyardSystemUpdate_v6.0.0.0.exe” program.
:
:
After [ Get Device Mode ], “The device is in BOOT LOADER mode” confirmation appears
in the window.
:
:
Select the relevant “ *.ATA ” file i,e, ARM……ata
:
:
