A diagrammatic map of the complete menu structure is provided below for quick reference.
Menu Structure
Logo Screen Time Screen
Audio Menu
Video Menu
Timecode Menu
Genlock Menu
System Setup Menu
Temp Report
Event Report
System Report
GPS Report
Configuration
Network
NTP Menu
DashBoard
Option Enable
Calibration
82 Audio Channel screens
7 Video Channel screens
20 Time screens
SNMP
IP Address
Subnet Mask
Gateway
MAC Address
Backup Device
Figure 3.1 : CY460 SPG – Menu Map (diagrammatic).
