PARTS DIAGRAM
*NOT SHOWN IN DIAGRAM
# ITEM NUMBER DESCRIPTION QTY
1 351302250132 BURNER GRATE 10
2 351128051028 BURNER ASSEMBLY (SHORT) 5
3 351128051027 BURNER ASSEMBLY (LONG) 5
4 35128059001 FRONT COUNTERTOP 1
5 35128059003 GAS CONTROL ASSEMBLY 1
6 35128059007 FRONT CONTROL PANEL 1
7 351202230111
BURNER KNOB 10
BURNER KNOB CORE 10
8
351301130111
OVEN KNOB 2
OVEN KNOB CORE 2
9 35128078022 SIDE PANEL (LEFT) 1
10 35128059005 OVEN DOOR ASSEMBLY 2
11 351228059011 30” KICK PLATE 2
12 351302140137 ORIFICE ELBOW 2
13.a 351302150198 ORIFICE #36 - OVEN NAT 2
13.b 351302150189 ORIFICE #50 - OVEN LP 2
14 351302170058 THERMOCOUPLE 2
15 351302130384 OVEN TUBE BURNER 2
16
351302090149 ADJUSTABLE LEG 6
351190487 LEG MOUNTING PLATE 6
17 35128078024 SIDE PANEL (RIGHT) 1
18.a 351302130427 PILOT OVEN NAT 2
18.b 351302130447 PILOT OVEN LP 2
19 35128059004 OVEN TANK ASSEMBLY 2
20 351228058007 CRUMB TRAY 19” X 26” 1
21 351128051007 INNER FLUE ASSEMBLY 2
22 351228051044 SLIDE RAIL (REAR BAFFLE) 2
23 351228046015 GAS PIPE (PILOT) (SHORT BURNER) 5
24 351228046016 GAS PIPE (PILOT) (LONG BURNER) 5
25 351302130019 STOVE PILOT 10
26 351302060231 PIPE FIXER 1
27 351128059006 BACK PANEL ASSEMBLY 1
28* 351228051012 CRUMB TRAY 31” X 32” 1
29* 351302140195 BRASS FITTING (THERMOCOUPLE) 1
30* 351228080018 THERMOCOUPLE PLATE 1
31* 351050081 EXTERNAL REGULATOR 1
32* 351302090155 CASTER W/BRAKE OPTIONAL
33* 351302090156 CASTER W/NO BRAKE OPTIONAL
34* 351CASTER6 CASTER SET OF 6 OPTIONAL
