STEP 4: Insert the battery.
Insert the battery with the contacts in, logo facing up, until it clicks into place and is fully encased in the
router. If you have selected the optional second battery, repeat this process for the second battery.
STEP 5: Reinstall the battery door.
Replace the battery door and use the door screw to secure.
STEP 6: Attach the LTE cellular antennas.
Install the 2 paddle antennas on the MAIN and DIV ports.
STEP 7: Mount the router.
The E100 router may be mounted in a number of ways, including placed on a desk, affixed to a wall, or
mounted on the ceiling. Refer to the following for best practices:
DESK
• Install the rubber feet (included) on the bottom of the router.
• Place the router on a flat surface away from objects that cause RF interference, including concrete,
reflective and metal surface, microwaves, and so on.
WALL & CEILING
• Using the included mounting insert, mark the desired mounting location on the ceiling or wall using a
pen or marker.
• Ensure the mounting location is away from objects that cause RF interference, including concrete,
reflective and metal surface, microwaves, and so on.
• Pre-drill holes for the mounting screws.
• Use wall anchors to ensure the endpoint is securely mounted.
STEP 8: Connect the Ethernet cable.
Connect the Ethernet cable to the port marked WAN on the back of the E100. Connect the other end to
your cable modem.
STEP 9: Power up the router.
• Connect the power supply to the router and then plug the other end into an electrical outlet.
