Craftex B1012 - Band Saw Parts List

15
B1012 MEAT CUTTING BAND SAW
Parts List
CODE PART # DESCRIPTION QTY. CODE PART # DESCRIPTION QTY
0001 01001 Parent 1 0043 010043 Upper Blade 1
0002 990234 Hex Head screw 4 0044 010044 Blade 1
0003 991743 F.Washer 12 0046 990233 Hex Head Screw 6
0004 010004 Cover 1 0048 010048 H Rod Cover 1
0005 010005 Lwr. Blade Wheel 1 0049 990871 P.H.Screw 2
0006 010006 Seat Bearing 2 0050 010050 Fixed Guide Seat 1
0008 990721 Set Screw 3 0051 991712 F. Washer 2
0011 990210 Hex Head Screw 2 0052 994167 Bearing 1
0012 991211 Nut 2 0053 990232 Hex Bolt 1
0013 991212 Nut 5 0055 010055 Clamping Luge 2
0014 991111 Nut 2 0056 011056 Table 1
0017 993025 V-Belt 1 0057 990622 Screw 14
0018 010018 Pulley 1 0058 990701 Screw 1
0019 994122 Bearing 2 0059 010059 Scale Bar 1
0020 990114 Hex Head Screw 2 0060 010060 Screw 3
0021 010021 Bracket 1 0061 010061 Blade Guide Bar 1
0022 010022 Charging Hopper 1 0062 994110 Bearing 1
0023 994163 Bearing 1 0063 992540 Retaining Ring 2
0024 992544 E-Ring 1 0064 010065 Blade Guide Block 1
0025 992013 Key 2 64-1 010064 Blade Guide Block 1
0026 010026 Shaft 1 0065 990721 Set Screw 1
0028 991598 Set Screw 1 0066 010066 Blade Guide Hldr 1
0029 990505 Lock Clamp 1 0067 010067 Connector Plate 1
0030 010030 Thrust Shaft 1 0068 010068 Lwr Wheel Shaft 1
0031 010031 Bushing 1 0069 010069 Rod Set Screw 1
0032 010032 Reamer 1 0070 010070 Blade Protec Plate 1
0033 010033 Filler Cover 1 0071 992522 Retaining Ring 1
0034 010034 Lock Cover 1 0072 010072 ‘L’ Guard Plate 1
0035 010035 Cover 1 0073 991214 Nut 1
0038 992545 Retaining Ring 1 0074 010074 Rubber Tube Con 1
0039 994123 Bearing 2 0076 010076 Pestle 1
0040 010040 Reg. Screw 1 0077 990710 Set Screw 4
0041 010041 Bracket 1 0078 991951 Spring Washer 1
0042 010042 Shaft Bracket 1 0079
0080
991751
991931
F. Washer
Spring Washer
1
1
