TRACTOR oo MODEL NUMBER 917.276021
KOHLER ENGmNE=MODEL NUMBER CV730,TYPE NUMBER 0017
CRANKSHAFT
KEY PART
NO, NO,
1. 24-014-72-S
2. 52=189=09=8
EXHAUST
KEY PART
NO, NO,
I.
2.
= =
= =
DESCRiPTiON
Crankshaft (includes 2)
Plug, cup
DESCRiPTiON
24=041=02=S Gasket, exhaust (2)
25=072=04=S Stud, M8x1.25x33 (4)
24 782 23 Miniblock
24 755 113=S Gasket Set
FUEL SYSTEM
KEY PART
NO. NO.
24-853-90-S
2. 24-041-52=S
3. 24-058-90
4. 24 041 14-S
5. M-629095=S
6. M-641060-S
7. 25-353-03-S
8. 25-237-14-S
9. 24-086-12-S
10. 24-393=16-S
1. 24-100-01-S
12. 24-353-03-S
13. 15-353=04-S
14. 24-050-02-S
NOT ILLUSTRATED
24 234 02-S
24 757 18-S
24 757 19-S
24 757 20-S
24 757 21-S
24 757 22-S
DESCRIPTION
Kit, carburetor w/gaskets
(includes 2-4)
Gasket, carburetor
Carburetor assembly
(For information only not
available separately)
(Service with 24 234 02=8 &
Kits 24 757 18-8, 24 757
19-S, 24 757 20-S, 24 757
21-S, & 24 757 22-S)
Gasket, air cleaner base
Stud, MSx1.0x95 (2)
Nut, hex. flange MSx1.0 (2)
Line, fuel 14"
Clamp, hose (6)
Screw, hex. cap. M6x1.7x18
(2)
Pump, fuel- pulse
Nut, plastic (2)
Line, fuel 10-5/8"
Line, fuel 11-1/2"
Filter, fuel
Bowl, float
Kit, overhaul
Kit, choke repair
Kit, gasket
Kit, accelerator pump repair
Kit, fuel shutdown solenoid
NOTE: All component dimensions given in U.S.
inches 1 inch = 25.4 mm
