Crane Source Space Vector SV100 User Manual

31
[Function No. 1] – Speed 1 in
the
User Level
is displayed at
power up.
[Function No. 2–Mac] is
displayed
This will take you into the
Program Mode
“0” is
initially
displayed
This saves the application
selection
Choose Application for Drive.
Traverse - Press once. “0” is displayed.
Hoist w/Load Brake - Leave “1” as is
Hoist without Load Brake - Press the key
once.“2” is displayed.
Section 2.3: Initial Setup Programming
2.3.1 Programming the Drive for a Specific Application
Initial setup programming involves a few easy steps. Follow the instructions shown in
Figure 2.3.1 below and your drive will be ready for operation.
Fig. 2.3.1: Programming Application Flowchart
* The drive has now been programmed for its appropriate application. According to your
new selection, other related drive parameters have conveniently changed automatically
for quick programming.
See Table 2.3.1 for the function parameters that are affected by the above Macro Quick
Set procedure.
Note: If so desired, these values can be changed individually by entering the respective
access level and changing the function data to customize the drive to your specific
application.
1
10.0
MAC
(MAC)
Turn on the power
to the SV100 drive
Press the
Key once
FUNC
Press the
Key once
FUNC
Press the
up key
once.
“1” is
initially
displayed
