Caution: The next example shows how to change data in the Advanced Level. It is
recommended that only trained SpaceVector™ service personnel change data
in this level.
Example 3:
Fig. 3.2.4: Change the rated slip of the motor from 3.0 Hz to 2.5 Hz.
Assume that you are currently in the User Level and you have not entered any password.
Press your or
keys until PAS is
displayed
Press the key.
Enter your
Advanced Level
password. Press
key again to enter
password. PAS will be
displayed again.
Press the
key until FU2
is displayed.
Press the
key. You will now
be in the
Advanced Level.
H1 will be displayed.
Press the key until H20
appears. Now press the
key. You will now be in
program mode. 3.0 will be
displayed.
Press your
key until 2.5
is displayed
Press the
key. This saves
your data selection.
H20 will be
displayed again.
To get back to the
User Level, press
your or
key until 88 is
displayed.
Press the
key. This allows
you to exit the
Advanced Level.
FU2 will now be
displayed.
Finished
