Crane 721 - Page 83

Model 721 Parts Manual
7210013 79
March, 2000
TABLE 44. TRAY ASSEMBLY DETAIL
INDEX PART NUMBER DESCRIPTION SNACK CANDY
GUM &
MINT
- 1597001 SNACK TRAY ASSEMBLY VARIES
- 1597002 CANDY TRAY ASSEMBLY VA RI E S
- 1597003 TRAY ASSEMBLY - 8 CANDY - 2 G&M VA RI ES
1 1677002 SPIRAL ASSEMBLY - DUAL G&M
2
2 1677003 SPIRAL - 2.65 DIA - DUAL G&M
1
3 1467137 RETAINER - SPIRAL ORANGE
1
4 1467130 DISC - SPIRAL INSERT
1
5 1677004 SPIRAL INSERT ASSEMBLY - BLACK
1
6 1467129 DISC - SPIRAL INSERT
1
7 1677005 CAP - SPIRAL INSERT
1
8 1477141 SPACER - ADJUSTABLE
43
9 1477083 RETAINER - SPIRAL - WALL (BAG ASSEMBLY) 10 10 10
10 1477175 WALL - TRAY 4 9 9
11 - LABEL - ITEM LETTERS (TABLE 49)
12 1477014 ROLL - PRICE CENTS 5 10 10
13 1477157 HOLDER - PRICE & SELECTION 1 1 1
14 1477134 RAIL - PRICE & SELECTION 1 1 1
15 2222031 TEE BOLT - TRIM 3 3 3
16 1477017 LATCH 2 2 2
17 5201267 PUSH ON RETAINER .312 2 2 2
18 1477148 ROLLER - TRAY 2 2 2
19 1477097 AXLE - TRAY ROLLER 2 2 2
20 1577040 TRAY - 5/10 DIVISION 1 1 1
21 1477156 JUMPER ASSEMBLY - MOTOR REVERSE
1
22 3502907 BUSHING 1 1 1
23 1679001 HARNESS - 10 MOTOR TRAY 1 1
1679000 HARNESS - 5 MOTOR TRAY 1
24 1477074 PUSHER - PRODUCT (BAG ASSEMBLY) 10 10 10
25 - SPIRAL (TABLE 45)
26 1477113 COUPLING - SPIRAL 10 10 10
27 1477020 GEAR - TRAY 10
28 1577038 MOTOR & PCB ASSEMBLY 5 10 8
1477114 - - 2
29 1477022 BEARING - COUPLER 5 - -
30 - SPIRAL RETAINER (TABLE 45)
31 - SPIRAL (TABLE 45)
ROLL - PRICE $21.00 TO $40.00
ROLL - PRICE $41.00 TO $60.00
ROLL - PRICE $1.00 - $12.00
ROLL - PRICE $12.00 TO $20.00
1679011
1679010
1677049
- 10 PUSHERS PER PACK
HALF CYCLE MOTOR FOR GUM & MINT SPIRAL
1477015
1570133
1570134
1570135
Not 
Shown
1677264
1577035
