Model 721 Parts Manual

80 7210013

March, 2000

TABLE 45. SPIRAL OPTIONS

LEFT HAND RIGHT HAND

SPIRAL

COUNT

RETAINER

COLOR

ASSEMBLY SPIRAL ASSEMBLY SPIRAL RETAINER

5 - - 1477178 - 1477179 -

6 PURPLE 1477103 1477102 1477105 1477104 1477107

9 GRAY 1477152 1477153 1477149 1477150 1477155

11 BLUE 1477023 1477024 1477026 1477027 1457061

13 YELLOW 1477029 1477030 1477032 1477033 1457062

15 RED 1477035 1477036 1477038 1477039 1457063

17 BROWN 1477101 1477100 1477099 1477098 1477106

20 WHITE 1477041 1477042 1477044 1477045 1457064

25 GREEN 1477047 1477048 1477050 1477051 1457065

30 BLACK 1477053 1477054 1477056 1477057 1477073

1677182

1677181

BROWN

BLUE

1677191

1677192

1677180

1677189

1677247

1677248

1677002

GUM / MINT

ORANGE
