Crane BARNES SITHE 4SCD Series - Page 28

28
CURRENT DESIGN (AFTER JAN.-2019)
Model
Striker Plate
Flange Size
Striker O-ring
Stock Kit
Shim Stock
Kit
Spacing
Kit
3SCMPA 3 INCH
Not Available in 28 Frame4SCMS 4 INCH
4SCDF 4 INCH
4SCMC 4 INCH
142635
142157-STK-KIT
142634
4SCMD 4 INCH
4SCMB 4 INCH
4SCME 4 INCH
4SCMEA 4 INCH
4SCDG 5 INCH 141579-STK-KIT
4SCDI 6 INCH
142158-STK-KIT
6SCMN 6 INCH
6SCMH 6 INCH
6SCMJ 6 INCH
6SCDO 6 INCH
6SCDK 8 INCH 143551-STK-KIT
8SCDU 10 INCH
143465-STK-KIT
8SCTM 10 INCH
10SCDW 12 INCH
143487-STK-KIT
10SCDX 12 INCH
PREVIOUS DESIGN (BEFORE FEB.-2019)
4SCDI 4 INCH
142635
142157-STK-KIT
142634
6SCDK 6 INCH 142158-STK-KIT
Striker Plate Kit includes:
• Striker Plate
• O-ring (Plate)
• M10 Bolts (qty. per table)
• Shim Kit
Shim Kit includes:
• 0.002” Shims (4)
• 0.004” Shims (4)
• 0.010” Shims (4)
• 0.025” Shims (2)
• 0.060” Shims (2)
• Level 4 Cut proof Gloves
• Spacer Gage
Striker Shell Kit includes:
• Striker Plate Kit
• Volute Kit
Striker Hardware Kit includes:
• M10 Bolts (qty. per table)
• O-ring (Plate)
Spacing Kit includes:
• Level 4 Cut proof Gloves
• Spacer Gage
Shim Stock Kit includes:
• 0.002” Shims (12)
• 0.004” Shims (12)
• 0.010” Shims (12)
• 0.025” Shims (8)
• 0.060” Shims (6)
Striker O-ring Stock Kit includes:
• Small O-ring (4 inch Plate)(qty. 4)
• Medium O-ring (5 inch Plate)(qty. 2)
• Large O-ring (6 inch Plate)(qty. 4)
• X-Large O-ring (8 inch Plate)(qty. 2)
• XX-Large O-ring (10 inch Plate)(qty. 4)
• XXX-Large O-ring (12 inch Plate)(qty. 4)
