Crane BARNES SITHE 4SCD Series - Page 36

36
“BA” Impeller
Trim Dia.
mm (in)
Ductile Iron
Slicer Blade Kit
Nihard
Slicer Blade Kit
Kit Component Info (Ref. ONLY)
Ductile Iron
Part No.
Nihard
Part No.
Blade Pin
320mm (12.60in) 143593-ASSY-KIT 143594-ASSY-KIT 143593-ASSY 143594-ASSY 142124 142133-0688
315mm (12.40in) 143593TA-ASSY-KIT 143594TA-ASSY-KIT 143593TA-ASSY 143594TA-ASSY 142124 142133-0688
310mm (12.21in) 143593TB-ASSY-KIT 143594TB-ASSY-KIT 143593TB-ASSY 143594TB-ASSY 142124 142133-0688
305mm (12.01in) 143593TC-ASSY-KIT 143594TC-ASSY-KIT 143593TC-ASSY 143594TC-ASSY 142124 142133-0688
300mm (11.81in) 143593TD-ASSY-KIT 143594TD-ASSY-KIT 143593TD-ASSY 143594TD-ASSY 142124 142133-0688
295mm (11.61in) 143593TE-ASSY-KIT 143594TE-ASSY-KIT 143593TE-ASSY 143594TE-ASSY 142124 142133-0688
290mm (11.42in) 143593TF-ASSY-KIT 143594TF-ASSY-KIT 143593TF-ASSY 143594TF-ASSY 142124 142133-0688
285mm (11.22in) 143593TG-ASSY-KIT 143594TG-ASSY-KIT 143593TG-ASSY 143594TG-ASSY 142124 142133-0688
280mm (11.02in) 143593TH-ASSY-KIT 143594TH-ASSY-KIT 143593TH-ASSY 143594TH-ASSY 142124 142133-0688
275mm (10.82in) 143593TJ-ASSY-KIT 143594TJ-ASSY-KIT 143593TJ-ASSY 143594TJ-ASSY 142124 142133-0688
270mm (10.63in) 143593TK-ASSY-KIT 143594TK-ASSY-KIT 143593TK-ASSY 143594TK-ASSY 142124 142133-0688
265mm (10.43in) 143593TL-ASSY-KIT 143594TL-ASSY-KIT 143593TL-ASSY 143594TL-ASSY 142124 142133-0688
260mm (10.24in) 143593TM-ASSY-KIT 143594TM-ASSY-KIT 143593TM-ASSY 143594TM-ASSY 142124 142133-0688
255mm (10.04in) 143593TN-ASSY-KIT 143594TN-ASSY-KIT 143593TN-ASSY 143594TN-ASSY 142124 142133-0688
250mm (9.84in) 143593TP-ASSY-KIT 143594TP-ASSY-KIT 143593TP-ASSY 143594TP-ASSY 142124 142133-0688
245mm (9.64in) 143593TQ-ASSY-KIT 143594TQ-ASSY-KIT 143593TQ-ASSY 143594TQ-ASSY 142124 142133-0688
240mm (9.45in) 143593TR-ASSY-KIT 143594TR-ASSY-KIT 143593TR-ASSY 143594TR-ASSY 142124 142133-0688
235mm (9.25in) 143593TS-ASSY-KIT 143594TS-ASSY-KIT 143593TS-ASSY 143594TS-ASSY 142124 142133-0688
230mm (9.05in) 143593TT-ASSY-KIT 143594TT-ASSY-KIT 143593TT-ASSY 143594TT-ASSY 142124 142133-0688
225mm (8.86in) 143593TU-ASSY-KIT 143594TU-ASSY-KIT 143593TU-ASSY 143594TU-ASSY 142124 142133-0688
220mm (8.66in) 143593TV-ASSY-KIT 143594TV-ASSY-KIT 143593TV-ASSY 143594TV-ASSY 142124 142133-0688
215mm (8.47in) 143593TW-ASSY-KIT 143594TW-ASSY-KIT 143593TW-ASSY 143594TW-ASSY 142124 142133-0688
210mm (8.27in) 143593TX-ASSY-KIT 143594TX-ASSY-KIT 143593TX-ASSY 143594TX-ASSY 142124 142133-0688
Slicer Blade Kit includes:
• Impeller (Balanced, trimmed)
• Blade (Pressed)
• Attachment Pins (Pressed)
(Components are Fully Assembled)
Slicer Blade Attachment Kit includes:
• Impeller Washer
• Impeller Bolt
• Impeller Key
