37
Seal Kits
Seal Kit
Part No.
I.B. Seal
Part No.
I.B. Seal
Material
O.B. Seal
Part No.
O.B Seal
Material
138635 129900 Carbon / Ceramic 129900 Carbon / Ceramic
138582 (STD) 129900 Carbon / Ceramic 129900SD Silicon Carbide / Silicon Carbide
138636 129900 Carbon / Ceramic 129900SB Tungsten Carbide / Tungsten Carbide
138637 129900SD Silicon Carbide / Silicon Carbide 129900SD Silicon Carbide / Silicon Carbide
138638 129900SD Silicon Carbide / Silicon Carbide 129900SB Tungsten Carbide / Tungsten Carbide
138639 129900SB Tungsten Carbide / Tungsten Carbide 129900SB Tungsten Carbide / Tungsten Carbide
Bearing Kit includes:
• Bearing Retaining Snap Ring
• Large Ball Bearing
• Small Ball Bearing
• Wavy Spring Washer
Bearing Bracket Kit includes:
• Bearing Bracket (painted)
• Large Pipe Plug
Seal Plate Kit includes:
• Small Spring Pin
• Large Pipe Plug
• Seal Plate (painted)
Terminal Block includes:
• Terminal Block
• Terminal Block O-Ring
• Green Wire Jumper
• Terminal Block Screw
Hardware Kit includes:
• Socket Head Cap Screws (for Housing)
• Impeller Bolt and Washer Set
• Flat Head Counter Sunk Screws (for Housing)
• Socket Head Cap Screws (for Motor Cap)
• Socket Head Cap Screws (for Seal Plate, Bearing
Bracket and Volute)
• Hex Washer Head Screw (for Moisture Sensor)
Moisture Sensor Kit includes:
• 18” Orange Wire Jumper
• 24” Blue Wire Jumper
• Moisture Sensor Resistor
• Moisture Sensor
• 36” Orange Wire Jumper
• Wire Connector Clip
• 24” Orange Wire Jumper
Seal Kit includes:
• Volute O-Ring (option 1)
• Volute O-Ring (option 2)
• Volute O-Ring (option 3)
• Volute O-Ring (option 4)
• Volute O-Ring (option 5)
• Seal Plate Upper O-ring
• Stator Upper and Lower O-rings
• Terminal Block O-ring
• External Retaining Ring
• Key
• Upper Mechanical Seal
• Lower Mechanical Seal
• Cord Attachment O-ring
NOTE: Kit contains hardware your pump may not require.
Motor Cap Kit includes:
• Motor Cap (painted)
Volute Kit includes:
• Wear Ring (PRESSED)
• Volute (painted)
(Components are Fully Assembled)
To Next Page
