CHART ‘B’
MODEL
NO
HP VOLT PH Hz
RPM
(Nom)
NEMA
START
CODE
FULL
LOAD
AMPS
SERVICE
FACTOR
SERVICE
FACTOR
AMPS
LOCKED
ROTOR
AMPS
CORD
P/N ▲
CORD
SIZE
CORD
O.D.
WINDING
RESISTANCE
SITHE SCDI Pump
4SCDI20064 20.0 208 3 60 1750 G 63.0 1.2 74.6 323.0 138318 6/4 - 18/4 1.14 ± .03 0.098
4SCDI25094 25.0
208
3 60 1750 G
77.8 1.2 93.4
359.0 138319 2/4 - 18/4 1.47 ± .03 0.098
230 71.4 1.2 82.3
4SCDI30094 30.0
208
3 60 1750 E
93.4 1.2 116.9
359.0 138319 2/4 - 18/4 1.47 ± .03 0.098
230 82.3 1.2 98.7
4SCDI40034 40.0 230 3 60 1750 E 106.0 1.2 126.4 486.0 138319 2/4 - 18/4 1.47 ± .03 .063
4SCDI40044 40.0 460 3 60 1750 E 53.0 1.2 63.2 243.0 138318 6/4 - 18/4 1.14 ± .03 .248
4SCDI40054 40.0 575 3 60 1750 E 42.4 1.2 50.6 194.4 138317 8/4 - 18/4 1.12 ± .02t .382 4SCDI50044 50.0 460 3 60 1750 F 67.1 1.2 79.0 339.0 138318 6/4 - 18/4 1.14 ± .03 .15
4SCDI50054 50.0 575 3 60 1750 F 53.7 1.2 63.2 271.2 138318 6/4 - 18/4 1.14 ± .03 .245
4SCDI60044 60.0 460 3 60 1750 E 79.0 1.2 95.5 339.0 138319 2/4 - 18/4 1.47 ± .03 .15
4SCDI60054 60.0 575 3 60 1750 E 63.2 1.2 76.4 271.2 138318 6/4 - 18/4 1.14 ± .03 .245
SITHE SCDI Pump
4SCDI20096 20.0
208
3 60 1150 H
60.3 1.2 71.5
354.0 138318 6/4 - 18/4 1.14 ± .03 .1117
230 57.2 1.2 69.8
4SCDI25096 25.0
208
3 60 1150 G
75.2 1.2 90.8
354.0 138319 2/4 - 18/4 1.47 ± .03 .1117
230 70.8 1.2 82.6
4SCDI25046 25.0 460 3 60 1150 G 35.4 1.2 41.3 177.0 138317 8/4 - 18/4 1.12 ± .02 .4397
4SCDI25056 25.0 575 3 60 1150 G 28.3 1.2 33.0 141.6 138317 8/4 - 18/4 1.12 ± .02 .6857
4SCDI30096 30.0
208
3 60 1150 E
90.8 1.2 114.9
354.0 138319 2/4 - 18/4 1.47 ± .03 .1117
230 82.6 1.2 99.7
4SCDI30046 30.0 460 3 60 1150 E 41.3 1.2 49.9 177.0 138317 8/4 - 18/4 1.12 ± .02 .4397
4SCDI30056 30.0 575 3 60 1150 E 33.0 1.2 39.9 141.6 138317 8/4 - 18/4 1.12 ± .02 .6857
4SCDI40036 40.0 230 3 60 1150 E 110.4 1.2 131.8 476.0 138319 2/4 - 18/4 1.47 ± .03 .0819
4SCDI40046 40.0 460 3 60 1150 E 55.2 1.2 65.9 238.0 138318 6/4 - 18/4 1.14 ± .03 .3277
4SCDI40056 40.0 575 3 60 1150 E 44.2 1.2 52.7 190.4 138317 8/4 - 18/4 1.12 ± .02 .5443
Moisture and Temperature sensor leads are integral to power cord. Winding Resistance ± 7.5% Winding resistance measured in OHMS @ 25°C (Between Lines) at motor leads. Pump rated for operation at ± 10% voltage at motor. ▲ Cord Sufx: XF - 50 Feet, XJ - 75 Feet, or XL - 100 Feet
▲ Cord sold separately.
