VFX5112/5212 Guitar Amplifier
System Block Diagram:
INPUT
GAIN
CHANNEL A
CHANNEL B
V1A
EL34
V5
EL34
V6
V4A
V4B
IMPEDANCE
SELECT
LINE
OUT
LINE
IN
CHANNEL
SELECT
V1B
V2A
VOL
V2B V3A
V3B
TREBLE
LEVEL
BASS
MODE LEVEL
MID
TREBLEBASS MID
DSP
EXT.
SPEAKE
R
SPEAKER
11

Table of Contents

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Crate VFX5112,VFX5212 and is the answer not in the manual?

Crate VFX5112,VFX5212 Specifications

VFX 5112

Power IconPower
output power rating50 Watts RMS
power requirements120 VAC, 60 Hz, 200VA
Sound IconSound
signal to noise ratio70 dB
gain channel A62 dB
gain channel B98 dB
Equalization IconEqualization
EQ Channel A Treble30 dB range @ 10 kHz
EQ Channel A Mid6 dB range @ 600 Hz
EQ Channel A Low30 dB range @ 80 Hz
EQ Channel B Treble10 dB range @ 4 kHz
EQ Channel B Mid10 dB range @ 1 kHz
EQ Channel B Low12 dB range @ 100 Hz
presence18 dB range @ 20 kHz
Speaker Specifications IconSpeaker Specifications
speaker configuration1 X 12”
speaker power60 W
speaker impedance16 ohm
Size and Weight IconSize and Weight
width23 inches
height19 inches
depth10 inches
weight48 lbs

VFX 5212

Power IconPower
output power rating50 Watts RMS
power requirements120 VAC, 60 Hz, 200VA
Sound IconSound
signal to noise ratio70 dB
gain channel A62 dB
gain channel B98 dB
Equalization IconEqualization
EQ Channel A Treble30 dB range @ 10 kHz
EQ Channel A Mid6 dB range @ 600 Hz
EQ Channel A Low30 dB range @ 80 Hz
EQ Channel B Treble10 dB range @ 4 kHz
EQ Channel B Mid10 dB range @ 1 kHz
EQ Channel B Low12 dB range @ 100 Hz
presence18 dB range @ 20 kHz
Speaker Specifications IconSpeaker Specifications
speaker configuration2 X 12”
speaker power60 W
speaker impedance8 ohm
Size and Weight IconSize and Weight
width28 inches
height21 inches
depth11 inches
weight58 lbs
