VFX5112/5212 Guitar Amplifier
VFX 5112/5212 TECHNICAL SPECIFICATIONS:
OUTPUT POWER RATING 50Watts RMS @ 5 % THD 16 ohm load 120 VAC
SIGNAL TO NOISE RATIO 70dB Typical
GAIN Channel A: 62 dB
Channel B: 98 dB
EQ - CH. A Treble: 30dB range @ 10kHz
Mid: 6dB range @ 600Hz
Low: 30dB range @ 80Hz
EQ - CH. B Treble: 10dB range @ 4kHz
Mid: 10dB range @ 1kHz
Low: 12dB range @ 100Hz
PRESENCE 18dB range @ 20kHz
SPEAKER SPECS VFX 5112: 1 X 12”, 60w, 16 ohm, 1.75” voice coil diameter, 38oz. magnet
VFX 5212: 2 X 12”, 60w, 8 ohm, 1.75 voice coil diameter, 38oz. magnet
PREAMP TUBES (4) 12AX7A
POWER TUBES (2) EL34
POWER REQUIREMENTS 120 VAC, 60 Hz, 200VA
100/115 VAC, 50/60 Hz, 200VA
230 VAC, 50/60 Hz, 200VA
SIZE AND WEIGHT VFX 5112: 23”W x 19” H x 10”D, 48 lbs.
VFX 5212: 28”W x 21” H x 11”D, 58 lbs.
The VFX 5112/5212 is covered with a durable Tolex material: wipe it clean with a lint-free cloth.
Never spray cleaning agents onto the cabinet. Avoid abrasive cleansers which would damage the finish.
Specifications and information in this manual are subject to change without notice.
www.v-seriesamps.com
@2002 St. Louis Music, Inc • 1400 Ferguson Avenue • St. Louis, MO 63133
47-036-03 • 062503
