Creality HALOT-MAGE User Manual

0108
5. Leveling Platform

󽗋󽗉
3. Move up the z-axis to a proper position, remove the calibration card and install the resin vat back, and then tighten the fixing screws at both ends of the
resin vat.
1. After loosening the leveling screws, press
the "Homing" on the touch screen to keep
the platform balanced with the base plate.
2. Gently press the platform and tighten 4 screws clockwise, and the platform can be leveled
successfully.
10mm
Z :
0.10mm 1.00mm 10.00mm
10mm
Z : 0.10mm 1.00mm 10.00mm

Creality HALOT-MAGE Specifications

General

Build Volume	228 x 128 x 230 mm
Layer Resolution	0.01 - 0.2 mm
Light Source	Integral Light Source
Connectivity	USB, Wi-Fi
Printing Speed	Up to 60 mm/h
Layer Thickness	0.01 - 0.2 mm
UV LED matrix	Yes
Wavelength	405 nm
Print Speed	Up to 60 mm/h
Power Consumption	120W
Material Compatibility	405nm UV resin
LCD Resolution	8K (7680 x 4320 pixels)
Weight	12 kg
Print Technology	LCD-based SLA
Slicer Software	HALOT BOX
Power Input	100-240V, 50/60Hz
Operating System	Linux
Resolution	8K
