Creative Sound Blaster X-Fi - Connecting DAT;MiniDisc to I;O Console; I;O Console Connections

5. CoaxialSPDIFIn/Outjacks ConnecttheCoaxialSPDIFIn/Outjacksonrecording/playbackdevices
tothesejacks.
6. Coaxialcables(availableseparately)
ConnecttotheCoaxialSPDIFIn/OutconnectorsonyourX-FiI/ODrive
andyourplayback/recordingdevice.
ConnectingyourDATorMiniDiscrecordingdevicetotheSound
BlasterX-FiI/OConsole

Jack,ConnectororCable Description
1. Opticalcables(availableseparately)
ConnecttotheOpticalSPDIFIn/OutjacksonyourX-FiI/OConsoleand
yourplayback/recordingdevice.
2.
3.50mm(1/8-inch)opticalminiplug-to-
opticalSPDIFcable(availableseparately)
ConnectstotheOpticalSPDIFOutjackonyourX-FiI/OConsoleandto
theOpticalInjackonyourportableMiniDiscplayer/recorder.
3. CoaxialSPDIFIn/Outjacks
ConnecttheCoaxialSPDIFIn/Outjacksonrecording/playbackdevices
tothesejacks.
ConnecttotheCoaxialSPDIFIn/OutjacksonyourX-FiI/OConsoleand
