Jack,ConnectororCable Description
1. Opticalcable(availableseparately)
ConnectstotheOpticalSPDIFOutjackontheX-FiI/ODriveandthe
SPDIFInjackonyourMiniDiscrecorder.
2. OpticalSPDIFOutjack Connectrecordingdeviceswithopticaljackstothisjack.
3.
3.50mm(1/8-inch)opticalminiplug-to-
opticalSPDIFcable(availableseparately)
ConnectstotheOpticalSPDIFOutjackonyourX-FiI/ODriveandto
theOpticalInjackonyourportableMiniDiscplayer/recorder.
4. LineIn2/MicIn2jack
Connectamicrophone,anelectricguitarrunningthroughaPre-ampFX
Box,orotherline-leveldevicestothisjack.
5. Mini-MIDI-to-standard-MIDIadaptercables
ConnecttotheMIDIIn/OutconnectorsontheX-FiI/ODriveandtwo
standardMIDIcables(availableseparately).
6. StandardMIDIcables(availableseparately)
ConnecttotheMIDIIn/OutconnectorsonyourMIDIkeyboardandthe
twomini-MIDI-to-standard-MIDIadaptercablesprovided.
ConnectinginstrumentstoyourSoundBlasterX-FiI/OConsole
