Creative Sound Blaster X-Fi - Page 51

RearPanel

Jack,ConnectororCable Description
1. Opticalcable(availableseparately)
ConnectstotheOpticalSPDIFOutjackontheX-FiI/OConsoleandthe
SPDIFInjackonyourMiniDiscrecorder.
2.
3.50mm(1/8-inch)opticalminiplug-to-
opticalSPDIFcable(availableseparately)
ConnectstotheOpticalSPDIFOutjackonyourX-FiI/OConsoleandto
theOpticalInjackonyourportableMiniDiscplayer/recorder.
3. OpticalSPDIFOutjack Connectrecordingdeviceswithopticaljackstothisjack.
4. StandardMIDIcables(availableseparately)
ConnecttotheMIDIIn/OutconnectorsontheX-FiI/OConsoleandto
theMIDIIn/OutconnectorsonyourMIDIkeyboard.
Notes
*Availablewithsomemodelsofyouraudiodevice,orasanupgrade
accessoryinsomeregions.
Actualproductsmaydifferslightlyfromthosepictured.
