Configuration Guide — 8341B DSP-1282 & DSP-1283: SIP Endpoint with Mitel 8.0 PR3 • 5
InputConfiguration
Toconfiguretheanaloginput:
1. ClickSignal.
Crestron Aviatool:Audio InputConfiguration (1/4)
2. Under AnalogIn1 (firstrow),doubleclickGain.Inthenewwindowsetthefollowing:
a. Click MutetoOff.
b. Select33for theAnalogGain.
c. If acondenser microphoneisbeingused,click +48V(phantom power)toOn.
Crestron AviaTool: AudioInputConfiguration(2/4)
3. Under AnalogIn1 (firstrow),clickRef/PhoneOut(right-mostcolumn)andenter 0
asthedecibelvalue.
Crestron AviaTool: AudioInputConfiguration(3/4)
4. Under Phone\SigGenIn,clickPHN.In thenewwindowsetthefollowing:
a. MovetheSendLevelslider to0db.
b. Click MutetoOff.
Crestron AviaTool: AudioInputConfiguration(4/4)
