7 • CEN-GW1 and CENI-GW1 Product Manual — Doc. 9195A
Power over Ethernet for Simple Installation
Using PoE technology, a single cable run is used for both power and data for the CEN-GW1.
Power an entire network of Crestron PoE devices using a Crestron PoE switch (CEN-SW-POE-5
or CEN-SWPOE-16) or a single device using a PoE Injector (PWE-4803RU). All PoE injectors and
switches are sold separately.
As an alternative to PoE, use a 24VDC power pack (PW-2407WU, sold separately) to power the
CEN-GW1.
Integrator Friendly Enclosure
Mount the CEN-GW1 almost anywhere using the Integrator Friendly Enclosure (IFE). The IFE can
be mounted to any flat surface, snapped onto a standard DIN rail, or stacked on other IFE
compliant devices. Rack mount and pole mount kits are also available.
Notes:
1. The CEN-GW1 is not compatible with MTX-3, TPS-6X, or UFO-WPR-3ER model remotes.
2. Battery-powered infiNET EX devices do not provide expander functionality and may have reduced RF range
capabilities. Consult the specifications for each network device to confirm its actual wireless capabilities. Use
infiNET EX expanders (CLW-EXPEX, sold separately) to fill gaps in coverage and extend the wireless range of the
infiNET EX network. infiNET EX expanders are only for infiNET EX networks and offer no benefit to the
performance of ER and SG devices. A maximum of five infiNET EX expanders may be deployed on an infiNET EX
network.
3. Up to six MLX-3 remotes can be used.
Physical Description
The following sections provide information about the connectors, controls, and indicators that
are available on the CEN-GW1 and CENI-GW1.
