Temperature Sensor Connections (TEMP SENSE)
Wire the eight temperature sensors to the TEMP SENSE terminals. Connecting a temperature
sensor input enables the use of the corresponding zone valve. Connect one temperature sensor
per heat zone. Crestron recommends using CAT3 (up to 76m (250ft)) or CAT5 (up to 152m
(500ft)) network cable. If other wire is used, the total capacitance must be less than 7,000 pF
(up to 152m (500ft)).
NOTES:
l
When wiring the temperature sensors:
o
Use a separate run of wire for each sensor. If using multi-conductor cable, use
only one pair per cable.
o
Do not run temperature sensor lines parallel to any other wiring. Cross cables at
right angles.
o
In situations where ordinary two-conductor thermostat wire (18 to 20 gauge)
has been installed, it may be used for runs up to 30m (100ft). This is not a
preferred method of installation.
l
The DIN-1TSTAT8 works with the following Crestron temperature sensors:
o
CHVI-RTS-1G-SM-W
o
CHVI-RTS-1G-N-W
o
CHV-RTS
o
CHV-RSS.
Cresnet Connections (NET)
Wire the Crestron control system, and other daisy-chained Cresnet devices, to the NET terminals
on the thermostat.
