Product Manual — Doc. 9368A DIN-1TSTAT8 • 15
Verify System Operation
After the thermostat is installed and programmed, enter Test mode to verify that each heating
zone is operating correctly. During Test mode, the thermostat performs a heat call on that zone.
To test the zone valve:
NOTE: To exit Test mode, press and hold the desired zone button for 10 seconds.
1. Press and hold the 1-8 button for 10 seconds to enter Test mode on the associated zone.
2. Verify that the zone valve operates as expected. The DIN-1TSTAT8 performs a 5-minute
heat call on that zone. If the valve is programmed to have a time delay, the delay is
initiated and added to the test call for heat. The zone LED flashes for the duration of Test
mode. The zone valve, main valve, and DIN-1TSTAT8 return to their previous states when
Test mode has been completed
NOTES:
l
The time delay is set per the manufacturers specifications.
l
The run-time for Test mode is determined by the time of the delay plus the 5-minute
heat call. Test mode can take up to 10 minutes to complete.
