Product Manual — Doc. 9368A DIN-1TSTAT8 • 7
TEMPSENSE
1–8
(8) 2-pin detachable terminal blocks;
Temperature sensor inputs for zones 1-8;
Each input accepts one sensor, model CHVI-RTS-1G-SM-W, CHVI-RTS-1G-N-W,
CHV-RTS, or CHV-RSS (sold separately);
Requires a dedicated low-capacitance twisted pair wire per zone (<7 nF per
run);
Supports wire lengths of 76m (250ft) using CAT3 or 152m (500ft) using
CAT5;
Thermostat wire is not recommended, but may be used if necessary at lengths
up to 30m (100ft);
Controls and Indicators
1 – 8 (8) Red LEDs and (8) pushbuttons, each button toggles the corresponding zone
output on and off (press and hold 10 seconds for test call), each LED indicates
the corresponding zone output is on (flashes with heat call, steady without heat
call)
MAIN (1) Red LED and (1) pushbutton, button toggles the main output on and off
when held 10 seconds, LED indicates the main output is on (flashes with heat
call, steady without heat call)
SETUP (1) Recessed pushbutton and (1) red LED for Cresnet TSID (touch-settable ID)
PWR (1) Green LED, indicates device is powered via Cresnet
NET (1) Yellow LED, indicates Cresnet communication with the control system
RESET (1) Recessed pushbutton for hardware reset
Power
Cresnet Power Usage 6W (250mA @ 24VDC)
Power Consumption <6W
Environmental
Temperature -18° to 43°C (0° to 110°F)
Humidity 10% to 90% RH (noncondensing)
Heat Dissipation 20BTU/hr maximum
For indoor use only
Construction
Housing Light gray polycarbonate housing with polycarbonate label overlay, UL94 V-0
rated
Mounting 35mm DINEN60715 rail mount, DIN43880 form factor for enclosures with
45mm front panel cutout, occupies 9DIN module spaces (162mm)
Dimensions
Height 94 mm (3.68 in.)
Width 161 mm (6.33 in.)
Depth 60 mm (2.34 in.)
